Which dimensions should I confirm for ISI 9" Reel?
Confirm flange diameter, barrel diameter, bore, traverse and overall width against the winding or pay-off equipment.
ISI 9" Reel
ISI standard 9 inch reel for industrial cable applications.
Specifications
- Size: 9"
- Flange Dia (d1): 230mm
- Barrel Dia (d2): 110mm
- Traverse (L2): 122mm
- Overall (L1): 162mm
- Bore (d4): 40mm
Application guidance
Numbered reel sizes for cable and wire applications that reference ISI-format dimensions.
Buyer questions
Can I request a quotation for ISI 9" Reel?
Yes. Include quantity, application, material preference and any dimensional changes with the enquiry.
How do I check whether ISI 9" Reel suits my application?
Compare the listed specifications with the equipment and send the wire or cable type, package weight and operating requirements for application matching.
